7. Connect headphones and/or a audio out to the headphones and audio in jacks on the monitor as
needed. As an alternative to headphones, you can connect low wattage speakers to the
headphones jack.
8. Secure the cables in place with the cable management clip. Press the clip straight down on the
curved neck of the pedestal ensuring that the tabs on the sides of the clip snap into the slots on
the pedestal.
Turning on the Monitor
1. Press the power button on the computer to turn it on.
2. Press the power button on the front of the monitor to turn it on.
CAUTION: Burn-in image damage may occur on monitors that display the same static image on
screen for a prolonged period of time.* To avoid burn-in image damage on the monitor screen, you
should always activate a screen saver application or turn off the monitor when it is not in use for a
prolonged period of time. Image retention is a condition that may occur on all LCD screens. Monitors
with a “burned-in image” are not covered under the HP warranty.
* A prolonged period of time is 12 consecutive hours of non-use.
NOTE: If pressing the power button has no effect, the Power Button Lockout feature may be
enabled. To disable this feature, press and hold the monitor power button for 10 seconds.
NOTE: You can disable the power LED in the OSD menu. Press the Menu button on the front of the
monitor, then select Management > Bezel Power LED > Off.
When the monitor is powered on, a Monitor Status window will show the following information:
●
The current status (Active or No Signal) for all three video inputs (USB, DisplayPort and VGA),
●
The current setting for the Auto-Switch Input option (On or Off),
●
The current setting for the Default Input option (USB, DisplayPort, VGA with USB selected as
the factory default),
●
The current detected display resolution,
●
The recommended native preset display resolution.
8 Chapter 2 Setting Up the Monitor ENWW
