6. If you are using the monitor as a standard single monitor with a desktop computer, connect the

VGA cable between the monitor and computer. The video signal is sent over the VGA cable.

When using the VGA cable, the port replicator features will not function.

If you are connecting an HP notebook computer to the monitor, connect one end of the provided

USB cable to a USB connector on the computer, and the other end to the upstream USB

connector on the monitor. The video signal is sent over the USB cable and the port replicator

features will be functional. For more information, refer to

Connecting an HP Notebook Computer

and Installing Drivers on page 9.

NOTE: If you are connecting an HP notebook computer to the monitor using a USB cable, you

do not need to connect the VGA cable or DisplayPort cable.

Connect the DisplayPort cable between the monitor and computer.

ENWW Connecting the Monitor Cables 7

Questions and Answers:

Need help?

Do you have a question about the HP EliteDisplay S231d and is the answer not in the manual?

HP EliteDisplay S231d Specifications

General

3D	-
Pixel pitch	0.265 x 0.265 mm
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 60 Hz
Horizontal scan range	24 - 80 kHz
Viewable size, vertical	286.4 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509 mm
Display brightness (typical)	250 cd/m²
HDCP	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
HDMI ports quantity	0
USB Type-A downstream ports quantity	2
Product color	Black
Country of origin	China
Market positioning	Business
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power consumption (standby)	2.2 W
Power consumption (typical)	38 W
Sustainability certificates	ENERGY STAR
