HP EliteOne 800 G1 Quickspecs

QuickSpecs
HP EliteOne 800 G1 21.5-inch Non-Touch All-in-One
PC
Standard Features and Configurable Components
Worldwide — Version 1.4 — February 19, 2014
Page 18
TEMPERATURE, HUMIDITY, ALTITUDE
Temperature
Operating
50° to 95° F (10° to 35° C)*
Non-operating
–22° to 140° F(–30° to 60° C)
Relative humidity
Operating
10% to 90% (non-condensing at ambient)
Non-operating
5% to 95% (non-condensing at ambient)
Altitude
(unpressurized)
Operating
10,000 ft (3048 m)
Non-operating
30,000 ft (9144 m)
PORTS
I/O Ports - Standard
4 - USB 3.0 (2 side including 1 fast charging, 2 rear)
USB Fast Charging Port:
 Up to 2.5A charging current (5 times the maximum current supported by a USB 2.0 port)
 D+/D– CDP/DCP Modes per USB Battery Charging Specification 1.2
 D+/D– Shorted Mode per Chinese Telecommunication Industry Standard YD/T 1591-2009
 Supports non-BC1.2 Charging Modes by Automatic Selection
 D+/D– Divider Modes 2.0V/2.7V and 2.7/2.0V
 D+/D- 1.2V Mode
 Supports Sleep-Mode Charging
 Automatic SDP/CDP Switching for Devices That do not Connect to CDP Ports
2 - USB 2.0 (2 rear)
2 – PS/2 (legacy) (one keyboard, one mouse)
1 – Microphone in (side)
1 – Headphone jack (side)
1 – Serial RS-232 (rear) (optional)
1 – Stereo audio line out (rear)
1 – Power connector (rear)
1 – RJ-45 (rear)
1 – DisplayPort with multi-stream
2
DisplayPort connector supports multimode technology to support connection to DVI-D, HDMI and VGA monitors with
optional adapters or to a DisplayPort monitor with a DisplayPort Cable.
DisplayPort Cable
Provides a direct connection between the PC’s DisplayPort interface to the
display’s DisplayPort interface
2
Using the Integrated Graphics, two (2) external displays are supported via one of these methods
1) DisplayPort multi-stream monitors ‘daisy-chained’ together or
2) DisplayPort multi-stream hub – hub requires power through power cable provided. DisplayPort multi-stream hub provides 4 DisplayPort
ports, adapters are required for support of DVI, VGA or HDMI displays.

HP EliteOne 800 G1 Specifications

General

RAM	DDR3
Memory	DDR3
Graphics	Intel HD Graphics 4600
Ports	4x USB 3.0, DisplayPort, VGA, RJ-45
Wireless	802.11a/b/g/n Wi-Fi, Bluetooth 4.0
Dimensions	56.09 x 5.28 x 38.28 cm (22.08 x 2.08 x 15.07 in)
Processor	Intel Core i3/i5/i7 (4th Gen)
Weight	8.4 kg
