HP EliteOne 800 G1 Quickspecs

QuickSpecs
HP EliteOne 800 G1 21.5-inch Non-Touch All-in-One
PC
Standard Features and Configurable Components
Worldwide — Version 1.4 — February 19, 2014
Page 8
Intel® HD Graphics 4600*
Graphics controller
DisplayPort
Intel® Processor Graphics
Multi-Stream support (supports up to 2 external displays)
1
Memory
Up to 1.8GB DDR3
Supported Graphics
APIs
DX11.1, OpenGL 4.0, OpenCL 1.2, full 1080p Blu-Ray Disc (H264) playback in
hardware
* HD content required to view HD images.
WIRELESS DISPLAY
WiDi support with Intel® Advanced-N 6205 WLAN or Intel® Dual Band Wireless-N 7260 (mini PCI Express) and
Intel® HD graphics.*
Desktop system requirements for Intel® Wireless Display
System Component
Requirement
Processor
4
th
generation Intel® Core processor
Graphics
Intel® HD Graphics
Wireless
Intel® Advanced-N 6205 WLAN or Intel® Dual Band Wireless-N 7260
Software
Intel® My WiFi Technology and Intel® Wireless Display must be pre-installed and
enabled.
OS
Windows 7 32-bit/64-bit Home Premium, Ultimate, Professional; Windows 7 32-bit
Home Basic; Windows 8 64-bit Professional
*Integrated Intel WiDi software is available on select models only and requires separately purchased projector, tv or
computer monitor with an integrated or external Wi-Di receiver. External Wi-Di receivers connect to the projector,
tv or computer monitor via a standard VGA, HDMI cable, also sold separately."
DISPLAY
21.5”diagonal IPS widescreen WLED backlit anti-glare LCD; Orientation designed to operate in portrait or landscape
Display Panel
Type
IPS WLED Backlit LCD
Viewable image area (mm)
476.06 x 267.79
Screen opening (mm)
477.73 x 269.22
Native Resolution (HxV)
1920 x 1080
Aspect ratio
16:9
Pixel pitch (HxV)(mm)
Contrast ratio (typical)
0.248 x 0.248
1000:1
Brightness (typical)
250 nits (cd/m
2
)
Viewing angle (typical) (HxV)
178 ° x178 °
Backlight lamp life (to half brightness)
30,000 hours minimum
Color support
Over 16 million colors
Color gamut (typical)
72%
Anti-glare
Yes
Default color temperature
Warm (6500K)
NOTE: All performance specifications represent the typical specifications provided by HP's
component manufacturers; actual performance may vary either higher or lower.
1
Using the Integrated Graphics, two (2) external displays are supported via one of these methods:
1) DisplayPort multi-stream monitors ‘daisy-chained’ together or
2) DisplayPort multi-stream hub – hub requires power through power cable provided. DisplayPort multi-stream hub provides 4 DisplayPort ports,
adapters are required for support of DVI, VGA or HDMI displays.

HP EliteOne 800 G1 Specifications

General

RAM	DDR3
Memory	DDR3
Graphics	Intel HD Graphics 4600
Ports	4x USB 3.0, DisplayPort, VGA, RJ-45
Wireless	802.11a/b/g/n Wi-Fi, Bluetooth 4.0
Dimensions	56.09 x 5.28 x 38.28 cm (22.08 x 2.08 x 15.07 in)
Processor	Intel Core i3/i5/i7 (4th Gen)
Weight	8.4 kg
