HP EN Series

Drive Support
Quantity
Supported
Position
Supported Controller
Removable Media
1.44-MB Diskette Drive 1 1 Floppy
Compaq SuperDisk (LS-120
Drive) 2X High-Capacity Floppy
Drive
1 1 IDE
24X Max Slimline CD-ROM Drive 1 2 IDE
6X Slimline DVD-ROM Drive 1 2 IDE
Hard Drives
27.0-GB 7200 rpm SMART III
Ultra ATA 66 Hard Drive
1 3 IDE
20.0-GB 5400 rpm SMART III
Ultra ATA Hard Drive
1 3 IDE
13.5-GB 7200 rpm SMART III
Ultra ATA 66 Hard Drive
1 3 IDE
10.0-GB 7200 rpm SMART III
Ultra ATA 66 Hard Drive
1 3 IDE
10.0-GB 5400 rpm SMART III
Ultra ATA Hard Drive
1 3 IDE
6.4-GB 5400 rpm SMART III
Ultra ATA Hard Drive
1 3 IDE
Overview
Standard Features
Options
Memory
Storage
TechSpecs
TechSpecs
System Unit
Dimensions (HxWxD) 3.56 x 12.5 x 14.6 in/9 x 31.8 x 37.1 cm
Weight (approximate) 20 lbs/9.1 kg
Weight Supported 100 lbs/45.5 kg
Power Supply
Operating Voltage Range 90 to 132 VAC/180 to 264 VAC
Rated Voltage Range 100 to 120 VAC/200 to 240 VAC
Rated Line Frequency 47 to 63 Hz
Rated Input Current 2.4A/1.2A
Maximum Rated Power 90W
Temperature
Ambient Air Temperature 50
°
to 95
°
F/10
°
to 35
°
C
Storage 50
°
to 122
°
F/10
°
to 50
°
C
Humidity
Operating 10% to 90%
Non-operating 10% to 90%
Maximum Altitude
Operating 10,000 ft/3,048 m
Non-operating 30,000 ft/9,144 m
Enhanced Keyboard
Dimensions (HxWxD) 1.5 x 18 x 6.5 in/3.81 x 45.72 x 16.51
cm
Weight 3.15 lbs/1.59 kg
QuickSpecs
Compaq Deskpro EN Series Small Form Factor
DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Page 20
