Mass storage devices
Item Component Spare part number
(1) Hard drive (7mm SATA 2.5”)
320-GB, 7200-rpm hard drive 634862–005
320-GB, 5400-rpm hard drive 645193–005
500-GB 5400-rpm hard drive 683802–005
(2a) Hard drive bracket 686594–001
(2b) Hard drive cable 686594–001
(3) Hard drive (mSATA solid-state drive)
32-GB solid-state (SSD) drive 687100–001
128-GB solid-state (SSD) drive 687101-001
(4) Optical drive
Blu-ray ROM DVD±R/RW Super Multi Double-Layer Drive 659941-001
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive 659940-001
Screws (not illustrated)
18 Chapter 3 Illustrated parts catalog
