Disconnect the webcam cable (1), and then remove the cable (2).
Display hinges and hinge covers
Description Spare part number
Display hinges 686596–001
Display hinge covers 686595–001
Before removing the webcam assembly:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the display panel (see
Display panel on page 32).
5. Remove the base enclosure (see
Base enclosure on page 34).
6. Disconnect the battery cable (see
Battery on page 36).
Component replacement procedures 69
