HP Ethernet 1Gb 4-port 366M User Manual

General Specifications Network controller Intel® Ethernet I350 Controller
Data rate Four ports, each at 1000 Mbps full duplex (theoretical maximum)
NOTE: The 366M adapter transmits from the server at only 2 Gbps aggregate
full duplex per port.
Bus type x4 PCI Express 2.1
Form factor Type I mezzanine card compatible with all ProLiant c-Class Gen8 servers listed
in the Supported Servers section of this QuickSpecs, all mezzanine slots.
Multiple cards per server.
NOTE: If the 366M is installed in mezzanine slot 1 of a half-height server,
connectivity will be provided on only 2 of the 4 ports.
IEEE Compliance 802.1p, 802.1Q, 802.3, 802.3ad, and 802.3x, IEEE 1588, 802.1AS
Power and Environmental
Specifications
Operating Temperature 50° - 95° F (10° - 35° C)
Humidity 10% to 90% non-condensing
Non-operating Temperature -40° to 158° F (-40° to 70° C)
Humidity 5% to 95% non-condensing
Power Maximum Watts 3.1 Watts
Emissions FCC Class A
Agency Approvals USA FCC (CFR 47 part 15) and UL 60950
RoHS Compliance 6 of 6
Safety UL Mark (USA and Canada)
CE Mark
EN 60590
Operating System
Support
Microsoft Windows Server 2008
Microsoft Windows HPC Server 2008
Red Hat Enterprise Linux 5.7, 6.1
SUSE Linux Enterprise Server
Solaris 10
VMware ESX/ESXi 4.1u2 and ESXi 5.0u1
Citrix Xenserver 6.0
Microsoft Windows Hyper-V
NOTE: For more operating system support & certification information, please visit
http://h10018.www1.hp.com/wwsolutions/index.html .
QuickSpecs
HP Ethernet 1Gb 4-port 366M Adapter
Technical Specifications
DA - 14335 North America — Version 8 — April 18, 2014 Page 8

HP Ethernet 1Gb 4-port 366M Specifications

General

Ports	4
Speed	1Gb
Form Factor	Low profile
Network Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Product Type	Network Adapter
Data Transfer Rate	1 Gbps per port
Ports Type	RJ-45
Interface	PCIe 2.1
Interface Type	PCI Express
Compatibility	HP ProLiant servers
