Setting Up the Monitor
User’s Guide 3–13
Assembling the f Monitor Satellite Speakers
To assemble the two satellite speakers for the f monitor:
1. Invert each speaker as shown in the following illustration.
2. Hold a speaker base inverted over the inverted speaker. With
the opening in the base toward the back of the speaker, match
the speaker center tab 1 with the base key slot 2, and then
lower the base onto the speaker.
2
1
