Display panel
Description Spare part number
13.3-in, LED, BrightView SVA display panel 672350-001
Before removing the display panel, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the base enclosure screws (see
Base enclosure on page 25).
5. Remove the keyboard (see
Keyboard on page 26).
6. Remove the top cover (see
Top cover on page 28).
7. Disconnect the battery cable (see
Battery on page 32).
Remove the display panel:
1. Turn the computer right-side up, with the front toward you.
2. Open the computer.
3. Disconnect the display panel cable from the system board (1).
4. Disconnect the USB/Audio board cable from the system board (2).
5. Disconnect the #1 and #2 WLAN antenna cables from the WLAN module (3).
NOTE: The #1 WLAN antenna cable is connected to the WLAN module #1 terminal. The #2
WLAN antenna cable is connected to the WLAN module #2 terminal. For more information, see
WLAN module on page 36,
34 Chapter 4 Removal and replacement procedures
