Illustrated parts catalog
Maintenance and Service Guide 3–3
Item Description Spare part number
1 43.9-cm (17.3-in) High Definition (HD), light-emitting diode (LED) BrightView display
assembly for use in:
Display 599078-001
Display with webcam 599079-001
2Keyboard (includes keyboard cable) for use in:
Belgium 600715-A41
French Canada 600715-121
France 600715-051
Germany 600715-041
Greece 600715-DJ1
International 600715-B31
Italy 600715-061
North America 600715-001
Norway 600715-DH1
Portugal 600715-131
Russia 600715-251
Saudi Arabia 600715-171
Spain 600715-071
Switzerland 600715-BG1
Turkey 600715-141
United Kingdom 600715-031
3 Power button board (includes cable) 600718-001
4 Speakers (2) 600848-001
5 Top cover (includes TouchPad board) 600716-001
6 TouchPad button board 595203-001
7 Fan/heat sink assembly (includes replacement thermal material) for use with:
UMA systems 595832-001
Discrete systems 595833-001
8 Processor (includes replacement thermal material)
Intel Core i7-620M Processor (4M cache, 2.66 GHz, SC turbo up to 3.33 GHz) 587259-001
Intel Core i5-540M Processor (3M cache, 2.53 GHz, SC turbo up to 3.06 GHz) 594188-001
Intel Core i5-520M Processor (3M cache, 2.4 GHz, SC turbo up to 2.93 GHz) 594187-001
Intel Core i5-430M Processor (3M cache, 2.26 GHz, SC turbo up to 2.53 GHz) 597624-001
Intel Core i3-350M Processor (3M cache, 2.26 GHz) 597623-001
Intel Core i3-330M Processor (3M cache, 2.13 GHz) 597622-001
9 RTC battery 602745-001
10 Memory module (1066 MHz, DDR3)
1 GB 598859-001
2 GB 598856-001
