3–10 Maintenance and Service Guide
Illustrated parts catalog
Mass storage devices
Item Description Spare part number
1Hard drive (includes Hard Drive Hardware Kit)
500 GB, 7200 rpm 603784-001
320 GB, 7200 rpm 603783-001
250 GB, 7200 rpm 605606-001
Hard Drive Hardware Kit (not illustrated, includes bracket and screws) 609493-001
2 Optical drive (includes bezel and bracket)
DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe 602542-001
Blu-ray ROM with LightScribe DVD±R/RW SuperMulti Double-Layer Drive 602543-001
