3–8 Maintenance and Service Guide
Illustrated parts catalog
Item Description Spare part number
1 Display bezel
With webcam and microphone modules 599086-001
With microphone module only 599085-001
2 Webcam board 600166-001
3 High-definition BrightView display panel (includes display panel and backlight cables) 599080-001
4 Display hinges 600711-001
LCD cable kit (not illustrated, includes LCD cable and webcam cable) 599087-001
5 Display hinge covers 600650-001
6 Wireless antenna (includes wireless antenna transceivers and cable) 600713-001
7 Microphone and cable 600714-001
8 Display enclosure (includes logo) 599082-001
Display Rubber Kit (not illustrated, includes display bezel rubber screw covers) 595198-001
Display Screw Kit (not illustrated) 600712-001
