Using the Main Menu and NCL
To do the procedures described in this chapter, you will use the Main
Menu screen and one or more of its menu options—in particular, the
Network Control Language Interpreter (NCL).
The Main Menu screen appears on the console after you connect to the
router module using HP Stack Manager (using the procedure on pages
1-22 – 1-23).
You can select an option from the Main Menu by either:
Typing the number preceding it.
Moving the pointer to the option, then pressing [Enter].
Pointer
Quick Configuration Utility
Configuration Editor
NCL
System name
Figure 2-1. Main Menu
Setup
2
Installation
Using the Main Menu and NCL
2-3
