HP AdvanceStack Router 210 Module:
An Overview
The HP AdvanceStack J2628A Router 210 Module is an auxiliary module
for the HP AdvanceStack J2603B Ethernet SNMP Module, which is an
optional component of an HP AdvanceStack 10Base-T Hub. The
HP AdvanceStack 10Base-T hubs into which the router module can be
installed (together with the SNMP module) include:
HP AdvanceStack J2600A 10Base-T Hub-12
HP AdvanceStack J2601A 10Base-T Hub-24
HP AdvanceStack J2602A 10Base-T Hub-48
Status LEDs
Reset
button
Clear
button
WAN port
connector
Battery (maintains the configu-
ration in RAM when the hub is
powered off)
SNMP module
connector
(internal LAN port)
iv
