7-8
Link Layer Discovery Protocol (LLDP and LLDP-MED)
LLDP Global Statistics
Table 7-6. LLDP Global Statistics Fields
Click Clear All Counters to reset all statistics to their initial values.
Field Description
Global Statistics
Insertions The number of times the complete set of information advertised by a particular MAC
Service Access Point (MSAP) has been inserted into tables associated with the remote
systems.
Deletions The number of times the complete set of information advertised by a particular MSAP
has been deleted from tables associated with the remote systems.
Drops The number of times the complete set of information advertised by a particular MSAP
could not be entered into tables associated with the remote systems because of insufficient
resources.
Age Outs The number of times the complete set of information advertised by a particular MSAP
has been deleted from tables associated with the remote systems because the information
timeliness interval has expired.
Time Since Last Update Time when an entry was created, modified, or deleted in the tables associated with the
remote system.
Interface Statistics
Interface The interface ID.
Transmitted Frames The number of LLDP frames transmitted on the interface.
Received Frames The number of valid LLDP frames received on the interface.
Discarded Frames The number of LLDP frames the interface discarded for any reason.
Errors The number of invalid LLDP frames received by the LLDP agent on the interface.
MED TLVs The total number of LLDP-MED TLVs received on the interface.
