PDU Cable ROW JG722A#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch/Router to Wall Power Cord JG722A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 870 Unified Wired-WLAN Appliance JG723A
12 RJ-45 autosensing 100/1000 ports
12 SFP 100/1000 Mb/s ports (min=0 \ max=12 SFP Transceivers)
4 SFP+ 10GbE ports (min=0 \ max=4 SFP+ Transceivers)
1 RJ-45 serial console port
1 RJ-45 out-of-band management port
1 - JG527A HP X351 300W AC Power Supply Included
2 U Height
See Configuration
Note:2, 3, 6, 7
PDU Cable NA/MEX/TW/JP JG723A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW JG723A#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch/Router to Wall Power Cord JG723A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
PDU CABLE NA/MEX/TW/JP JG647A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
220 NA JG647A#B2E
NEMA L6-20P Cord
PDU CABLE NA/MEX/TW/JP JG646A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
220 NA JG646A#B2E
NEMA L6-20P Cord
Configuration Rules:
Note 1 The following Transceivers install into this Switch:
HP X125 1G SFP LC LH40 1310nm Transceiver JD061A
HP X120 1G SFP LC LH40 1550nm Transceiver JD062A
HP X125 1G SFP LC LH70 Transceiver JD063B
HP X120 1G SFP LC SX Transceiver JD118B
HP X120 1G SFP LC LX Transceiver JD119B
QuickSpecs
HP 830 Unified Wired-WLAN Switch Series
Configuration
DA - 14560 Worldwide — Version 8 — June 10, 2014 Page 7
