13
1410-24-R switch
Front panel
Figure 5 1410-24-R front panel
(1) 10/100Base-TX port (2) Port LED (3) Power LED (Power)
Rear panel
Figure 6 1410-24-R rear panel
(1) Grounding screw (2) AC-input power receptacle
1410-24G-R switch
Front panel
Figure 7 1410-24G-R front panel
(1) 10/100/1000Base-T port (2) Port LED (3) Power LED (Power)
