HP L2335 User Manual

User’s Guide www.hp.com 3–1
3
Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the
monitor, computer system, and other attached devices, then
follow these steps:
1. Place the monitor in a convenient, well-ventilated location
near your computer.
2. Connect one end of the monitor signal cable to the video
connector on the rear panel of the computer, and the other end
to the back of the monitor.
✎
The DVI-D cable supplied with this monitor is for digital-
to-digital connection only. Your computer must have a
DVI-compatible graphics card installed for use with this cable.
When connecting the DVI-D signal cable to the DVI connector
on the monitor, you must connect the other end of the DVI-D
cable to the DVI connector on the computer.

HP L2335 Specifications

General

3D	No
Pixel pitch	0.258 x 0.258 mm
Aspect ratio	16:9
Response time	16 ms
Display diagonal	23 \
Display resolution	1920 x 1200 pixels
Contrast ratio (dynamic)	-
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Digital vertical frequency	48 - 85 Hz
Digital horizontal frequency	30 - 94 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1152 x 870, 1920 x 1200 (WUXGA)
DVI-D ports quantity	0
LED indicators	Power
Tilt angle range	-5 - 25 °
Height adjustment	90 mm
Cable lock slot type	Kensington
On Screen Display (OSD)	Yes
Panel mounting interface	100 x 100 mm
AC input frequency	50 - 60 Hz
Power consumption (typical)	100 W
Power requirements	90 - 265V
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	ACA, CSA, CE, CCIB/CCEE, CISPR, FCC, TUV/GS, VDT, NOM, MIC, MPR-II, PC2001, PC99, BSMI, TCO, TUV-Ergo, UL, VCCI
Country of origin	China
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	85 mm
Width (without stand)	545 mm
Height (without stand)	370 mm
Weight (without stand)	10100 g
