HP L2335 User Manual

A–2 www.hp.com User’s Guide
Troubleshooting
Using the Worldwide Web
Before contacting customer services, refer to the support Web site
at:
http://www.hp.com/support
Image appears
blurred, indistinct, or
too dark.
Brightness and contrast
are too low.
Press the Menu button to
open the OSD Menu, and
adjust the brightness and
contrast scales as needed.
Image is not
centered.
Position may need
adjustment.
Press the Menu button to
access the OSD menu.
Select Image Control to
adjust the horizontal or
vertical position of the
image.
“Check Video
Cable” is displayed
on screen.
Monitor video cable is
disconnected.
Connect the 15-pin monitor
video cable to the VGA
connector on the computer.
Be sure that the computer
power is off while
connecting the video cable.
“Input Signal Out of
Range” is displayed
on screen.
Video resolution and/or
refresh rate are set
higher than what your
monitor supports.
Restart your computer and
enter Windows Safe Mode
by pressing the F8 Function
key when the computer starts
to boot up. Change your
settings to a supported
setting. Restart your
computer so that the new
settings take effect.
Problem Possible Cause Solution

HP L2335 Specifications

General

3D	No
Pixel pitch	0.258 x 0.258 mm
Aspect ratio	16:9
Response time	16 ms
Display diagonal	23 \
Display resolution	1920 x 1200 pixels
Contrast ratio (dynamic)	-
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Digital vertical frequency	48 - 85 Hz
Digital horizontal frequency	30 - 94 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1152 x 870, 1920 x 1200 (WUXGA)
DVI-D ports quantity	0
LED indicators	Power
Tilt angle range	-5 - 25 °
Height adjustment	90 mm
Cable lock slot type	Kensington
On Screen Display (OSD)	Yes
Panel mounting interface	100 x 100 mm
AC input frequency	50 - 60 Hz
Power consumption (typical)	100 W
Power requirements	90 - 265V
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	ACA, CSA, CE, CCIB/CCEE, CISPR, FCC, TUV/GS, VDT, NOM, MIC, MPR-II, PC2001, PC99, BSMI, TCO, TUV-Ergo, UL, VCCI
Country of origin	China
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	85 mm
Width (without stand)	545 mm
Height (without stand)	370 mm
Weight (without stand)	10100 g
