d.) Rotate the back of the cover away form the printer, then slide the cover forward to remove right cover
2. Remove Left Cover
a.) Open toner cartridge door, use a small flat blade screwdriver to release one tab at the upper front of left cover
(Callout 3)
b.) Release one tab from the bottom of left cover (callout 4)
c.) Rotate the front of the left cover away the printer, then slide the left cover backwards to remove
To Next Page
