268 Parts and diagrams ENWW
Alphabetical parts list
Table 42. Alphabetical parts list
Description Part number Quantity Figure Ref.
250-sheet feeder C4793-67901 1 133
500-sheet feeder C7065-67901 1 134
Access plate feed guide assembly RG5-5554-030CN 1 128 7
Access plate solenoid assembly RM1-0331-000CN 1 128 10
Arm, paper sensor RB2-6310-000CN 1 130 5
Arm, sensor RB2-6264-000CN 1 126 8
Belt, paper feed RC1-0918-000CN 3 127 9
Bin extension RB2-6286-000CN 1 123 1A
Bushing, left RB2-2896-000CN 1 130 3
Bushing, left RB2-2896-000CN 1 133 4
Bushing, left RB2-2896-000CN 1 134 4
Bushing, right RB2-2895-000CN 1 130 2
Bushing, right RB2-2895-000CN 1 133 3
Bushing, right RB2-2895-000CN 1 134 3
Bushing, transfer, right RC1-0922-000CN 1 126 10
Button, power switch RB2-6294-000CN 1 123 8A
Cable guide assembly RM1-0324-000CN 1 127 13
Cable, panel RG1-4314-000CN 1 123 4
Cap, continuity RA0-1068-000CN 1 126 1
Control panel RH6-0226-000CN 1 123 5
Cover, DIMM RM1-0329-000CN 1 123 2
Cover, front RC1-1013-000CN 1 123 3
Cover, I/O RB2-6283-000CN 1 123 2A
Drive assembly RM1-0334-000CN 1 125 23
Duct RC1-1003-000CN 1 125 8
E-label reader assembly RM1-0335-000CN 1 125 17
Engine controller assembly RM1-0339-000CN 1 131
Engine controller PCA RG1-4307-000CN 1 131 1
Engine controller PCA RG1-4307-000CN 1 132 1
Fan RH7-1591-000CN 1 125 14
Feed roller assembly RG5-5555-000CN 1 128 8
FG cable assembly RG1-4310-000CN 1 125 10
Flat cable, I/F RH2-5580-000CN 1 125 12
Foot, rubber RB2-6297-000CN 4 126 9
Formatter Q1395-60001 1 132 3
Fuse (110-127V) WD1-0268-000CN 1 129 1B
