ENWW Chapter 8 Parts and diagrams 269
Fuse (220-240V) RH3-8006-000CN 1 129 1B
Fuser (110-127V) RM1-0354-000CN 1 125 24
Fuser (220-240V) RM1-0355-000CN 1 125 24
Gear assembly RM1-0337-000CN 1 127 14
Gear, 14T RS6-0445-000CN 1 126 19
Gear, 14T RU5-0156-000CN 1 127 18
Gear, 15T RU5-0168-000CN 1 126 21
Gear, 26T RC1-1039-000CN 1 126 12
Gear, 27T RU5-0155-000CN 1 127 17
Gear, 29T RC1-1040-000CN 1 126 13
Grounding cable RG5-5600-000CN 1 125 11B
Guide, cable RC1-1002-000CN 1 125 7
Guide, cartridge, left RB2-2831-020CN 1 126 3
Guide, cartridge, right RB2-2830-020CN 1 126 2
Guide, flat cable RC1-1019-000CN 1 125 9
Guide, rear output RB2-6401-000CN 1 123 1E
Hinge, feed guide RB2-6249-000CN 1 128 1
Hinge, left RB2-6405-000CN 1 127 2
Hinge, right RB2-6406-000CN 1 127 3
Holder, sensor, lever RL1-0158-000CN 1 129 3
I/F cable RG5-5599-000CN 1 125 11A
Inlet cable assembly RM1-0342-000CN 1 128 12
Laser/scanner RM1-0313-000CN 1 125 16
Left cover assembly RG5-5549-000CN 1 123 8
Lever, jam clearing RB2-6251-000CN 1 126 7
Lever, sensor RB2-2836-000CN 1 125 1
Motor, dc (M1) RH7-1587-000CN 1 125 13
Mount, fan RB2-6255-000CN 1 125 3
Mount, laser/scanner RC1-1001-000CN 1 125 6
Pad, separation RB2-9960-000CN 1 134 15
Pad, separation RC1-0939-000CN 1 127 11
Paper feeder cable RG5-5598-000CN 1 125 11
PCA VT2-0012-005CN 1 129 4
Photosensor TLP1242 WG8-5382-000CN 1 127 21
Pickup assembly RM1-0332-000CN 1 130
Pickup roller RB2-6304-000CN 1 130 4
Pickup roller RB2-6304-000CN 1 133 1
Pickup roller RB2-6304-000CN 1 134 1
Plate, feeding, center RC1-0912-000CN 1 127 4
Plate, feeding, front RC1-0915-000CN 2 127 7
Table 42. Alphabetical parts list (continued)
Description Part number Quantity Figure Ref.
