HP LaserJet 5100 series - Step 12. Connect printer cables

ENWW
start guide
21
Step 12. Connect printer cables
The HP LaserJet 5100 printer includes one interface: an IEEE-1284
parallel port.
The HP LaserJet 5100tn and 5100dtn printers also include an
HP Jetdirect print server with an additional fast Ethernet (10/
100Base-TX) port.
Figure 7 Interface ports
10/100Base-TX cable
and RJ-45 port
Parallel cable and
IEEE-1284 port
