HP LaserJet 5200 - Page 94

3. Lift up the separation pad (callout 2) to remove it.
2
Figure 5-10 Removing the tray 2 separation pad (3 of 3)
Tray 3 retard roller
1. Remove tray 3.
Figure 5-11 Removing the tray 3 retard roller (1 of 2)
74 Chapter 5 Removal and replacement ENWW
