Ref LaserJet 5L Part No. LaserJet 6L Part No. Qty Description
1 RG5-2024-000CN RB2-1719-000CN 1 Formatter Shield
2 C3942-67902 C3991-60001 1 Formatter, New
C3942-69002 n/a 1 Formatter, Exchange
3 RG5-2023-000CN RG5-3506-000CN 1 DC Controller PCA (110 V)
3 RG5-2025-000CN RG5-3509-000CN 1 DC Controller PCA (220 V)
3 C3941-69001 n/a DC Controller PCA (110 V)
Exchange
3 C3941-69002 n/a DC Controller PCA (220 V)
Exchange
4 RG5-3510-000CN RG5-3510-000CN 1 DC Controller PCA Case
Assembly
5 RG5-2036-000CN RG5-3499-000CN 1 Control Panel PCA Cable
6 XA9-0326-000CN XA9-0890-000CN 9 Screw, TP, M3x4
7 XA9-0828-000CN XA9-0828-000CN 1 Screw, WStar
8 RG5-2029-000CN RG5-2029-000CN 1 Paper Pickup Cable
9 RG5-2031-000CN RG5-3662-000CN 1 Door Sensor Cable
10 RG5-2032-000CN RG5-2032-000CN 1 Thermistor Cable
11 RG5-2033-000CN RG5-2033-000CN 1 Motor Cable
12 RG5-2034-000CN RG5-3661-000CN 1 Scanner Cable
13 RG5-2035-000CN n/a 1 Laser Cable
14 RG5-2037-000CN n/a 1 Door Switch Cable
VD7-0211-002CN VD7-0211-002CN 1 Fuse 101 (110 V)
VD7-0643-151CN VD7-0643-151CN 1 Fuse 101 (220 V)
RH3-8003-000CN RH3-8003-000CN 1 Fuse 102 (110 V)
Table 8-7 DC Controller Case
8
Parts and
Diagrams
Parts and Diagrams 8-17
