Fax Settings
The product can send scanned documents to a fax number to simulate the sending capabilities of a fax
machine. If the product is equipped with a fax modem, it can also be set up to process incoming faxes.
NOTE: The Fax Settings screen is available only if your product is equipped with a fax modem board.
NOTE: Fax settings can also be configured on the Configure Device page available from the
Settings tab.
Use the Fax Settings screen to configure the send-to-fax features for the product. The following
illustration and table describe how to use this screen.
Figure 5-1 Fax Settings screen
1
3
4
5
2
6
7
8
Table 5-1 Send to Fax
Callout Area on the screen Information or capability that the area provides
1 HP EWS tabs and
menus
For more information, see Navigating through the HP Embedded Web Server
on page 4.
2 Help Click to open a help file that contains information about the screens on the Digital
Sending tab.
96 Chapter 5 Using fax functions ENWW
