3. Disconnect two wire harnesses (callout 2; J551 and J556).
Figure 5-81 Remove the paper-pickup assembly (2 of 4)
2
4. Remove six screws (callout 3).
Figure 5-82 Remove the paper-pickup assembly (3 of 4)
3
ENWW Product base 101
