Problem-solving diagrams
●
Repetitive image defects
●
Interface ports
●
Formatter connectors
●
ECU connectors
●
Solenoid and motor
●
Rollers
●
Sensors
●
Major components
●
PCAs (base unit)
●
Circuit diagram
Repetitive image defects
If the product output has a consistent, repetitive defect, then use Table 6-1 Repetitive image defects
on page 140 to determine which part needs to be replaced based on the measured distance between
the repetitions of the defect.
NOTE: The following table replaces the graphical repetitive defect ruler. You can make your own ruler
by using these measurements.
Table 6-1 Repetitive image defects
Distance between identical
defects
Dirty or damaged roller Solution
26.7 mm (1.05 in) Primary charging roller Replace the print cartridge.
29.1 mm (1.14 in) Developing cylinder Replace the print cartridge.
39.3 mm (1.55 in) Transfer roller Replace the transfer roller.
56.2 mm (2.21 in) Pressure roller Replace the fuser.
56.5 mm (2.22 in) Fuser film (fuser sleeve) Replace the fuser.
140 Chapter 6 Problem solve ENWW
