Description Part number Table and page
Link, coupling RC2-2965-000CN Internal components (1 of 3)
on page 171
LJm1005 HP Jewel 7121-8285 Scanner assemblies
on page 165
Motor, 24V DC RM1-4196-000CN Internal components (3 of 3)
on page 175
Motor-controller PCA RM1-4935-000CN Internal components (3 of 3)
on page 175
Paper-delivery tray assembly RM1-4725-000CN Assemblies on page 167
Paper-pickup assembly RM1-4727-000CN Internal components (2 of 3)
on page 173
Paper-pickup tray assembly RM1-4722-000CN Assemblies on page 167
Roller, pickup RL1-1497-000CN Internal components (2 of 3)
on page 173
Roller, transfer RM1-4234-000CN Internal components (2 of 3)
on page 173
Scanner spring, tension RU6-2637-000CN Assemblies on page 167
Scanner-link assembly, left RM1-3953-000CN Assemblies on page 167
Scanner-link assembly, right RM1-3954-000CN Assemblies on page 167
Separation-pad assembly RM1-4207-000CN Internal components (2 of 3)
on page 173
SSA PKG FGI ASSY LJm1120 (scanner flatbed assembly) CB537-67901 Scanner assemblies
on page 165
Tray guide, left RC2-2979-000CN Internal components (3 of 3)
on page 175
Tray guide, right RC2-2980-000CN Internal components (3 of 3)
on page 175
Table 7-12 Alphabetical parts list (continued)
ENWW Alphabetical parts list 177
