Table 8-9 ADF components
Ref Description Part number Qty
2 Sheet, grounding scanner RL1-0376-000CN 1
3 Screw, tap, M4X10 XB4-5401-009CN 6
4 Cover, left scanner RM1-3076-020CN 1
6 Cover, right scanner RM1-3077-000CN 1
7 Flat, flexible cable (FFC) scanner RK2-1214-000CN 1
8A Cover, top RC2-5792-000CN 1
8B Control-panel assembly, Western RM1-5178-000CN 1
8B Control-panel assembly, Asian RM1-5179-000CN 1
8C Screw, tap, M4X10 XB4-5401-009CN 3
9 Scanner link assembly, right RM1-0897-000CN 1
10 Spring, tension scanner RU5-2885-000CN 1
11 Scanner link assembly, left RM1-0896-000CN 1
ENWW Scanner components and handset 215
