Table 8-11 Guide assembly
Ref Description Part number Qty
All Guide assembly, scanner RM1-3066-000CN 1
1 Screw, self tapping, M4X10 XB4-5401-009CN 5
2 Screw, D, M3X6 XA9-1670-000CN 1
6 Screw, self-tapping binding head, M3X8 XB4-7300-805CN 1
8 Scanner media-lever torsion spring (lever, pressure convert) RC1-2544-000CN 1
9 Scanner media lever (lever, pressure convert) RC1-8413-000CN 1
13 Spring, compression, white platen RU5-2196-000CN 3
14 Platen, white, scanner RF5-3235-000CN 1
20 Separation-pad assembly, scanner RM1-0890-000CN 1
20A Separation-pad set, scanner RM1-0891-000CN 1
NOTE: The separation-pad set and the separation-pad assembly are two different assemblies.
The separation-pad set consists of the pad, clear plastic sheet, and the pad cover. The separation-pad
set is a user-replaceable assembly.
The separation-pad assembly consists of the separation lever, tension spring, feed arm, and the
components of the separation-pad set. The separation-pad assembly is not a user-replaceable
assembly.
Only trained service personnel should attempt to replace the separation-pad assembly.
ENWW Scanner components and handset 219
