Table 8-15 Internal components (1 of 3)
Ref Description Part number Qty
1 Panel, rear RC1-8368-000CN 1
6 Separation-pad assembly, printer RM1-2048-000CN 1
7 Transfer-roller assembly RM1-2062-000CN 1
8 Power-supply assembly, 110-127 V RM1-5280-000CN 1
8 Power-supply assembly, 220-240 V RM1-5281-000CN 1
14 Guide, tray left RC1-8389-000CN 1
15 Screw, rs, M3X8 XA9-1420-000CN 4
16 Screw, D XA9-1670-000CN 19
20 Fuser, 110-127V RM1-5363-000CN 1
20 Fuser, 220-240V RM1-5364-000CN 1
21 Pickup assembly RM1-3043-000CN 1
22 Roller, pickup, printer (product base) RL1-0266-000CN 1
23 Guide, tray right RC1-8390-000CN 1
501 Screw, with washer, M3X6 XB2-7300-605CN 2
502 Screw, tap, M4X10 XB4-5401-009CN 1
ENWW Product base 227
