Table 8-16 Internal components (2 of 3)
Ref Description Part number Qty
6 Laser/scanner assembly RM1-2033-030CN 1
7 Engine-controller-PCB assembly RM1-3404-000CN 1
9 Latch, left RC1-2498-000CN 1
10 Latch, right RC1-2499-000CN 1
14 Screw, rs, M3X8 XA9-1420-000CN 2
15 Screw, rs, M2X10 XA9-1501-000CN 4
16 Screw, D XA9-1670-000CN 11
ENWW Product base 229
