Part number Description Table and page
RC1-8390-000CN Guide, tray right Internal components (3 of 3)
on page 231
RC1-8413-000CN Scanner media lever (lever, pressure convert) Guide assembly on page 219
RC2-5792-000CN Cover, top ADF components on page 215
RC2-5800-000CN Cover, right External covers, printer
on page 223
RF5-3235-000CN Platen, white, scanner Guide assembly on page 219
RK2-0777-000CN Motor, stepping, dc Internal components (3 of 3)
on page 231
RK2-1214-000CN Flat, flexible cable (FFC) scanner ADF components on page 215
RL1-0266-000CN Roller, pickup, printer (product base) Internal components (1 of 3)
on page 227
RL1-0376-000CN Sheet, grounding scanner ADF components on page 215
RL1-1160-000CN Cover, front External covers, printer
on page 223
RL1-1161-000CN Cover, top (scanner support-frame) External covers, printer
on page 223
RM1-0885-000CN Pickup-roller assembly, scanner Frame assembly on page 217
RM1-0890-000CN Separation-pad assembly, scanner Guide assembly on page 219
RM1-0891-000CN Separation-pad set, scanner Guide assembly on page 219
RM1-0896-000CN Scanner link assembly, left ADF components on page 215
RM1-0897-000CN Scanner link assembly, right ADF components on page 215
RM1-2033-030CN Laser/scanner assembly Internal components (2 of 3)
on page 229
RM1-2048-000CN Separation-pad assembly, printer Internal components (1 of 3)
on page 227
RM1-2062-000CN Transfer-roller assembly Internal components (1 of 3)
on page 227
RM1-3043-000CN Pickup assembly Internal components (1 of 3)
on page 227
RM1-3059-000CN Delivery tray assembly External assemblies and print
cartridge on page 221
RM1-3060-000CN Pickup tray assembly External assemblies and print
cartridge on page 221
RM1-3063-000CN Frame assembly Frame assembly on page 217
RM1-3066-000CN Guide assembly, scanner Guide assembly on page 219
RM1-3076-020CN Cover, left scanner ADF components on page 215
RM1-3077-000CN Cover, right scanner ADF components on page 215
RM1-3404-000CN Engine-controller-PCB assembly Internal components (2 of 3)
on page 229
Table 8-19 Numerical parts list (continued)
ENWW Numerical parts list 237
