USB PCA (fax/memory-card models)
Before proceeding, remove the following components:
●
Right cover. See Right cover on page 25.
●
Right-front cover and power button. See Right-front cover and power button on page 26.
Remove the USB PCA
Release one tab (callout 1), and then remove the USB PCA.
Figure 1-113 Remove the USB PCA (fax/memory-card models)
