HP LaserJet Pro Color MFP M476dn

2. Partially pull out the print-cartridge drawer, and then use a small flat blade screwdriver to release one
tab (callout 1) on the left side of the product.
Figure 1-23 Remove the print-cartridge drawer (1 of 3)
1
3. Carefully rotate the print-cartridge drawer toward the right side of the product to release it.
Figure 1-24 Remove the print-cartridge drawer (2 of 3)
ENWW Removal and replacement procedures 23
