Rear door
1. Open the rear door.
2. Use the green handle to close the duplex-feed assembly.
Figure 1-32 Close the duplex-feed assembly
3. Remove two screws (callout 1).
NOTE: Before you remove the rear door, take note of the mounting tabs on the door (callout 2).
Figure 1-33 Remove two screws
30 Chapter 1 Removal and replacement ENWW
