Paper-feed guide assembly
1. Release one screw (callout 1).
Figure 1-30 Remove the feed assembly (1 of 2)
1
2. Remove the feed assembly.
TIP: When the feed assembly is correctly reinstalled, the assembly will be able to move in relation to
the door. It should not be secured firmly to the door.
Figure 1-31 Remove the feed assembly (2 of 2)
