2. Open the duplex-feed assembly, release one tab (callout 1), and then slightly separate the cover from
the product.
Figure 1-36 Remove the rear-lower cover and rear-door links (2 of 6)
1
3. Release one tab (callout 1) and slightly separate the cover from the product.
Figure 1-37 Remove the rear-lower cover and rear-door links (3 of 6)
1
