2. Use a precision point (flat head) screwdriver to push the left-side metallic door pin out of the link.
NOTE: A precision point screwdriver is required to release the front door pins. The width of the blade
must be 2 mm (0.08 in) or less to be able to push the door pins out of the mounting holes.
Figure 1-62 Remove the front-door assembly (2 of 10)
3. Use a precision point (flat head) screwdriver to push the right-side metallic door pin out of the link.
NOTE: A precision point screwdriver is required to release the front door pins. The width of the blade
must be 2 mm (0.08 in) or less to be able to push the door pins out of the mounting holes.
Figure 1-63 Remove the front-door assembly (3 of 10)
ENWW Removal and replacement procedures 49
