Table 3-6 Assembly view, HP LaserJet Professional M1130 MFP series
Ref Description Part number Qty
1 Control panel, spring CE841-00014 1
2 Control panel (HP LaserJet Professional M1130 MFP series) CE841-60107 1
3 Control panel, mount CE841-40005 1
4 Ferrite, rectangular EMI ROHS 9170-1821 1
5 Cable engine, video FFC 3:1 CE847-60105 1
6 Cable, engine 24 V 3:1 CE847-60109 1
7 Nameplate, metal low profile 3.5 ROHS 7121-8265 1
8 Spacer, formatter CE847-40008 1
9 Formatter PCA assembly (HP LaserJet Professional M1130 MFP
series)
CE831-60001 1
10 Cover, I/O (HP LaserJet Professional M1130 MFP series) CE847-40009 1
11 Core-ferrite, ribbon core ROHS 9170-2385 1
12 Assylink, 3 in 1 CE847-60110 1
ENWW Assembly views 187
