Table 3-7 Assembly view, HP LaserJet Professional M1210 MFP series
Ref Description Part number Qty
1 Control panel, spring CE841-00014 1
2 Control panel, Western (HP LaserJet Professional M1210 MFP
series)
CE841-60110 1
2 Control panel, Asian (HP LaserJet Professional M1210 MFP
series)
CE841-60109 1
3 Control panel, mount CE841-40005 1
4 Ferrite, rectangular EMI ROHS 9170-1821 1
5 Jumper, fax PCA CE841-60116 1
6 Cable engine, video FFC 4:1 CE841-60108 1
7 Cable, engine 24 V 4:1 CE847-60107 1
8 Formatter PCA assembly (HP LaserJet Professional M1210 MFP
series)
CE832-60001 1
9 Fax card, Billow DAA US (HP LaserJet Professional M1210 MFP
series)
CE833-60001 1
9 Fax card, DAA Euro (HP LaserJet Professional M1210 MFP
series)
CE868-60001 1
9 Fax card, DAA Brazil (HP LaserJet Professional M1210 MFP
series)
CD643-60001 1
10 Nameplate, metal low profile 3.5 ROHS 7121-8265 1
11 Cover, I/O (HP LaserJet Professional M1130 MFP series) CE841-40026 1
12 Core-ferrite, ribbon core ROHS 9170-2385 1
13 Assylink, 4 in 1 CE841-60119 1
ENWW Assembly views 189
