Table 3-20 Internal assemblies (2 of 3)
Ref Description Part number Qty
1 Pickup transfer frame assembly RM1-7737-000CN 1
2 Transfer roller RM1-4023-000CN 1
3 Paper pickup sensor PCA assembly RM1-7894-000CN 1
4 Roller, paper pickup RL1-2593-000CN 1
5 Separation pad assembly RM1-4006-000CN 1
ENWW Internal assemblies 215
