Description Part number Table and page
Laser/scanner assembly RM1-6878-000CN Internal assemblies (3 of 3)
on page 217
Latch, ADF Q8191-00004 ADF pre-pick arm assembly;
HP LaserJet Professional
M1210 MFP series
on page 209
Lid, document base CE847-40003 Scanner assembly (1 of 2);
HP LaserJet Professional
M1130 MFP series
on page 191
Motor PCA assembly RM1-7895-000CN Internal assemblies (3 of 3)
on page 217
Motor PCA assembly RM1-7895-000CN PCAs on page 219
Motor, DC Q3434-60238 Scanner drive assembly;
HP LaserJet Professional
M1130 MFP series
on page 195
Motor, DC CE538-60128 Scanner drive assembly;
HP LaserJet Professional
M1210 MFP series
on page 201
Motor, DC 24 V RL1-2591-000CN Internal assemblies (3 of 3)
on page 217
Nameplate, metal low profile 3.5 ROHS 7121-8265 Assembly view, HP LaserJet
Professional M1130 MFP
series on page 187
Nameplate, metal low profile 3.5 ROHS 7121-8265 Assembly view, HP LaserJet
Professional M1210 MFP
series on page 189
Pad friction, ADF CB780-80008 ADF core; HP LaserJet
Professional M1210 MFP
series on page 207
Panel, rear RC3-0852-000CN Product base on page 211
Paper delivery tray assembly RM1-7727-000CN Product base on page 211
Paper pickup sensor PCA assembly RM1-7894-000CN Internal assemblies (2 of 3)
on page 215
Paper pickup sensor PCA assembly RM1-7894-000CN PCAs on page 219
Paper pickup tray assembly RM1-7728-000CN Product base on page 211
Pickup transfer frame assembly RM1-7737-000CN Internal assemblies (2 of 3)
on page 215
Power switch assembly RM1-7735-000CN Internal assemblies (1 of 3)
on page 213
Pre-pick arm assembly, ADF CB780-60032 ADF top cover; HP LaserJet
Professional M1210 MFP
series on page 205
Table 3-23 Alphabetical parts list (continued)
224 Chapter 3 Parts and diagrams ENWW
