Part number Description Table and page
RC3-0823-000CN Cover, left Product base on page 211
RC3-0825-000CN Cover, right Product base on page 211
RC3-0839-000CN Door, print cartridge Product base on page 211
RC3-0852-000CN Panel, rear Product base on page 211
RL1-2591-000CN Motor, DC 24 V Internal assemblies (3 of 3)
on page 217
RL1-2593-000CN Roller, paper pickup Internal assemblies (2 of 3)
on page 215
RL1-2944-000CN Cover, top Product base on page 211
RL1-2946-000CN Front cover Product base on page 211
RM1-4006-000CN Separation pad assembly Internal assemblies (2 of 3)
on page 215
RM1-4023-000CN Transfer roller Internal assemblies (2 of 3)
on page 215
RM1-6872-000CN Fuser film assembly (110 V) Internal assemblies (1 of 3)
on page 213
RM1-6873-000CN Fuser film assembly (220 V) Internal assemblies (1 of 3)
on page 213
RM1-6878-000CN Laser/scanner assembly Internal assemblies (3 of 3)
on page 217
RM1-7604-000CN Cable, flat Internal assemblies (3 of 3)
on page 217
RM1-7726-000CN Scanner lock assembly Product base on page 211
RM1-7727-000CN Paper delivery tray assembly Product base on page 211
RM1-7728-000CN Paper pickup tray assembly Product base on page 211
RM1-7733-000CN Fuser paper delivery assembly (110 V) Internal assemblies (1 of 3)
on page 213
RM1-7734-000CN Fuser paper delivery assembly (220 V) Internal assemblies (1 of 3)
on page 213
RM1-7735-000CN Power switch assembly Internal assemblies (1 of 3)
on page 213
RM1-7737-000CN Pickup transfer frame assembly Internal assemblies (2 of 3)
on page 215
RM1-7892-000CN Engine controll PCA (110 V) Internal assemblies (1 of 3)
on page 213
RM1-7892-000CN Engine control PCA assembly (110 V) PCAs on page 219
RM1-7893-000CN Delivery sensor PCA assembly Internal assemblies (1 of 3)
on page 213
RM1-7893-000CN Delivery sensor PCA assembly PCAs on page 219
RM1-7894-000CN Paper pickup sensor PCA assembly Internal assemblies (2 of 3)
on page 215
Table 3-24 Numerical parts list (continued)
232 Chapter 3 Parts and diagrams ENWW
