Scanner components
NOTE: This section describes replacement and removal of individual scanner components. To remove
the complete scanner assembly, see
Scanner assembly on page 30.
HP LaserJet Professional M1210 MFP series only: replacement and removal of the ADF pickup roller
and separation pad are described earlier in this chapter. See
ADF pre-pickup arm and pickup roller
on page 10 or ADF separation pad on page 14.
White plate (document backing)
1. Open the scanner lid.
Figure 1-58 Remove the white plate (1 of 3)
ENWW Scanner components 41
