2. Remove two screws (callout 1), and then remove the assembly (callout 2).
Figure 1-89 Remove the control-panel assembly (3 of 5)
1
2
3. Slide the assembly toward the left and then lift up on it to release the ratchet arm.
Figure 1-90 Remove the control-panel assembly (4 of 5)
ENWW Main assemblies 63
