HP LE1901w User Manual

3 Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other
attached devices, then follow the instructions below.
Attaching the Monitor Base
1. Set the base on a flat surface such as a table top.
2. Using both hands, position the pedestal over the base and press down firmly to lock it in place. Be
sure the base is securely locked in place and adjust the tilt angle to the desired position.
CAUTION: Do not touch the surface of the LCD panel. Pressure on the panel may cause non-
uniformity of color or disorientation of the liquid crystals. If this occurs the screen will not recover to its
normal condition.
Figure 3-1 Attaching the Base to the Monitor
ENWW Attaching the Monitor Base 5

HP LE1901w Specifications

General

3D	No
Pixel pitch	0.2835 x 0.2835 mm
Display diagonal	19 \
Display resolution	1440 x 900 pixels
Vertical scan range	56 - 76 Hz
Horizontal scan range	24 - 83 kHz
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	160 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	832 x 624, 1152 x 870, 1280 x 960, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Operating temperature (T-T)	5 - 35 °C
Certification	CE, FCC, CUL, CCIB, CCEE, IT ECO
Product color	Black
Country of origin	China
Plug and Play	Yes
LED indicators	Power
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
DVI-D ports quantity	0
Power consumption (standby)	2 W
Power consumption (typical)	29 W
Sustainability certificates	ENERGY STAR
Cables included	VGA

Weight and Dimensions

Depth (without stand)	59 mm
Width (without stand)	446 mm
Height (without stand)	301 mm
Weight (without stand)	4300 g
