4 Operating the Monitor
Software and Utilities
The CD that comes with the monitor contains files you can install on the computer:
●
an .INF (Information) file
●
an .ICM (Image Color Matching) file
●
auto-adjustment pattern utility
●
additional software for the monitor model
Adobe Reader is supplied on this CD and can be installed from the menu.
NOTE If the monitor does not include a CD, the .INF and .ICM files can be downloaded from
the HP monitors support Web site. See Downloading from the Worldwide Web in this chapter.
The Information File
The .INF file defines monitor resources used by Microsoft Windows operating systems to ensure
monitor compatibility with the computer’s graphics adapter.
This monitor is Microsoft Windows Plug and Play compatible and the monitor will work correctly
without installing the .INF file. Monitor Plug and Play compatibility requires that the computer’s
graphic card is VESA DDC2–compliant and that the monitor connects directly to the graphics card.
Plug and Play does not work through separate BNC type connectors or through distribution buffers/
boxes.
The Image Color Matching File
The .ICM files are data files that are used in conjunction with graphics programs to provide
consistent color matching from monitor screen to printer, or from scanner to monitor screen.
The .ICM file contains a monitor color system profile. This file is activated from within graphics
programs that support this feature.
NOTE The ICM color profile is written in accordance with the International Color Consortium
(ICC) Profile Format specification.
Software and Utilities 19

HP LP1965 Specifications

General

Operating temperature (T-T)	5 - 35 °C
Non-operating relative humidity (non-condensing)	5 - 90 %
Pivot angle	0 - 90 °
Plug and Play	Yes
Tilt angle range	-4 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
3D	No
HD type	-
Panel type	TFT
Pixel pitch	0.294 x 0.294 mm
Aspect ratio	4:3
Response time	6 ms
Display surface	Matt
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Display technology	LCD
Vertical scan range	48 - 76 Hz
Horizontal scan range	24 - 83 kHz
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display scanning frequency	Horizontal frequency: 24-83 kHz, Vertical frequency: 48-76 Hz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA)
UNSPSC-code	43211902
Audio included	No audio included No audio included at platform level
Rear ports note	4 USB 2.0
Native resolution	SXGA (1280x1024) pixels
Security features	Kensington Lock-ready
Weight (imperial)	15.6 lb lbs
Power requirements	Auto-ranging, 90 to 265 VAC, Internal power supply, 50 to 60 Hz (built-in power supply)
Recommended resolution	Preset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60, 70 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 76 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60, 72 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60, 72 and 75
Display resolution at frequency	Preset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60, 70 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 76 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60, 72 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60, 72 and 75 Hz
Dimensions (W x D x H) (imperial)	15.9 x 8.78 x 18.79 \
Product dimensions (without stand, imperial)	15.9 x 2.4 x 12.96 \
Product color	Black, Silver
Country of origin	China
AC input voltage	90 - 265 V
AC input frequency	50 - 60 Hz
Power consumption (max)	55 W
Power consumption (standby)	2 W
Power consumption (typical)	35 W
I/O ports	One upstream, four downstream ports (cable included)
USB hub version	2.0
DVI-D ports quantity	0
DVI-I ports quantity	2
USB Type-A downstream ports quantity	3
Cables included	AC, DVI
Interface adapters included	DVI-I female - VGA male

Weight and Dimensions

Depth (with stand)	222.9 mm
Width (with stand)	403.9 mm
Height (with stand)	377.2 mm
Weight (with stand)	7060 g
Depth (without stand)	61 mm
Height (without stand)	329.1 mm
Weight (without stand)	4190 g
